Introduction:
Parameters:
| Technical Parameter | GHDB-1600 | ||
| Saw blade diameter | mm | Φ1600-1pc | |
| Saw blade no. | pcs | 1 | |
| Max. up-down stroke | mm | 900 | |
| Max worktable stroke | mm | 3500 | |
| Worktable table-board dimensions | mm | 1680×988 | |
| Max. stone material cutting specs. | L×W | mm | 3000×1200 |
| H | mm | 650 | |
| Main motor model and power | kw | Y200L2-6 22 | |
| Up-down motor model and power | kw | Y90L-6 1.1 | |
| Trolley motor model and power | kw | YU802-6 0.55 | |
| Up-down motor model and power | Kw | Y112M-6 2.2 | |
| Water consumption | L/min | 80～100 | |
| Outline dimensions L×W×H | Mm | 6000×2900×3300 | |
| Weight | T | 4 | |
Display:
Video:
